WDR-240-24 MEANWELL SMPS Power Supply

WDR-240-24 MEANWELL SMPS Power Supply

Product Details:

  • Phase Three Phase
  • Output Current 10 Ampere (amp)
  • Output Type Single
  • Output Power 240 Watt (w)
  • Input Voltage 180-550VAC / 254-780VDC Volt (V)
  • Efficiency 91%
  • Weight 1.6 Kilograms (kg)
  • Click to View more
X

WDR-240-24 MEANWELL SMPS Power Supply Product Specifications

  • 10 Ampere (amp)
  • Three Phase
  • 180-550VAC / 254-780VDC Volt (V)
  • 91%
  • Single
  • 240 Watt (w)
  • 1.6 Kilograms (kg)

Product Description

Brand Name

Meanwell

Part No

WDR-240-24

Input Voltage Range

 180-550VAC OR 254-780VDC

Output Voltage

24VDC

Output Adjustable Voltage Range

24VDC -28VDC

Output Current

10Amp

Output Power

240Watt

Mounting Type

Din Rail / Channel Mount

Protections

Short Circuit / Overload / Over Voltage / Over Temperature

Efficiency

91%

Certifications

UL508,EAC TP TC 004 approved,IEC62368-1 CB approved by SIQ,design refer to BS EN/EN62368-1, AS/NZS 62368.1,GL;
(meet BS EN/EN60204-1)

Dimension

63 x 125.2 x 113.5 mm

Weight

1.06 KG
