SE-1000-15 MEANWELL SMPS power supply

SE-1000-15 MEANWELL SMPS power supply

Product Details:

  • Phase Single Phase
  • Output Type Single
  • Output Current 66.7 Ampere (amp)
  • Output Power 1000 Watt (w)
  • Input Voltage 90 - 132VAC / 180 - 264VAC OR 254 - 370VDC Volt (V)
  • Efficiency 86%
  • Weight 2.5 Kilograms (kg)
  • Click to view more
X

Product Specifications

  • 86%
  • 2.5 Kilograms (kg)
  • 66.7 Ampere (amp)
  • Single
  • Single Phase
  • 90 - 132VAC / 180 - 264VAC OR 254 - 370VDC Volt (V)
  • 1000 Watt (w)

Product Description

 Brand Name  Meanwell
 Part No  SE-1000-15
 Input Voltage Range  90 - 132VAC / 180 - 264VAC OR 254 - 370VDC
 Output Voltage  15 VDC
 Output Adjustable Voltage Range  13.5VDC - 16.5VDC
 Output Current  66.7Amp
 Output Power  1000 Watt
 Mounting Type  Enclosed / Panel Mount
 Protections  Short Circuit / Overload / Over Voltage / Over Temperature
 Efficiency   86%
 Certifications  UL62368-1, BSMI CNS14336-1, EAC TP TC 004 approved;   Design refer to BS EN/EN62368-1
 Dimension  278 x 127 x 63.5 mm
 Weight  2.5 KG
