Send InquiryRSP-100-15 MEANWELL SMPS Power Supply
RSP-100-15 MEANWELL SMPS Power Supply Specification
- Output Current
- 6.7 Ampere (amp)
- Phase
- Single Phase
- Output Type
- Single
- Output Power
- 100 Watt (w)
- Input Voltage
- 85 - 264AC / 120 - 370VDC Volt (V)
- Efficiency
- 87%
- Weight
- 0.52 Kilograms (kg)
About RSP-100-15 MEANWELL SMPS Power Supply
| Brand Name | Meanwell |
| Part No | RSP-100-15 |
| Input Voltage Range | 85 - 264AC / 120 - 370VDC |
| Output Voltage | 15VDC |
| Output Adjustable Voltage Range | 14.3VDC - 16.5VDC |
| Output Current | 6.7Amp |
| Output Power | 100 Watt |
| Mounting Type | Enclosed / Panel Mount |
| Protections | Short Circuit / Overload / Over Voltage / Over Temperature |
| Efficiency | 87% |
| Certifications | UL62368-1, TUV BS EN/EN62368-1, BS EN/EN61558-1, BS EN/EN61558-2-16, EAC TP TC 004, CCC GB4943.1, BSMI CNS14336-1 approved, Design refer to AS/NZS 62368.1 |
| Dimension | 179 x 99 x 30 mm |
| Weight | 0.52 KG |
Tell us about your requirement
Price:
Quantity
Select Unit
- 50
- 100
- 200
- 250
- 500
- 1000+
Additional detail
Mobile number
Email
More Products in RSP-100 MEANWELL SMPS Power Supply Category
RSP-100-12 MEANWELL SMPS Power Supply
Output Power : 100 Watt (w)
Output Type : Single
Efficiency : 86%
Input Voltage : 85 264AC / 120 370VDC Volt (V)
Weight : 0.52 Kilograms (kg)
Output Current : 8.5 Ampere (amp)
RSP-100-5 MEANWELL SMPS Power Supply
Output Power : 100 Watt (w)
Output Type : Single
Efficiency : 86%
Input Voltage : 85 264AC / 120 370VDC Volt (V)
Weight : 0.44 Kilograms (kg)
Output Current : 20 Ampere (amp)
RSP-100-48 MEANWELL SMPS Power Supply
Output Power : 100 Watt (w)
Output Type : Single
Efficiency : 88%
Input Voltage : 85 264AC / 120 370VDC Volt (V)
Weight : 0.52 Kilograms (kg)
Output Current : 2.1 Ampere (amp)
RSP-100-24 MEANWELL SMPS Power Supply
Output Power : 100 Watt (w)
Output Type : Single
Efficiency : 87%
Input Voltage : 85 264AC / 120 370VDC Volt (V)
Weight : 0.52 Kilograms (kg)
Output Current : 4.2 Ampere (amp)
