RQ-85B MEANWELL SMPS Power Supply

RQ-85B MEANWELL SMPS Power Supply

Product Details:

  • Phase Single Phase
  • Output Current 7 / 3.1 / 0.5 / 0.5 Ampere (amp)
  • Output Type Quad
  • Output Power 85 Watt (w)
  • Input Voltage 88 - 264VAC / 125 - 373VDC Volt (V)
  • Efficiency 76%
  • Weight 0.6 Kilograms (kg)
  • Click to view more
X

Product Specifications

  • 76%
  • 7 / 3.1 / 0.5 / 0.5 Ampere (amp)
  • 85 Watt (w)
  • Quad
  • Single Phase
  • 88 - 264VAC / 125 - 373VDC Volt (V)
  • 0.6 Kilograms (kg)

Product Description

Brand Name

MEANWELL

Part No

RQ-85B

Input Voltage Range

88 - 264VAC / 125 - 373VDC

Output Voltage

5VDC /  12VDC / -5VDC / -12VDC

Output Current

7Amp / 3.1Amp / 0.5Amp / 0.5Amp

Output Power

85Watt

Mounting Type

Enclosed / Panel Mount

Protections

Output Short Circuit / Over-Current / Over-Voltage

Efficiency

76%

Certifications

UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved

Dimension

159 x 97 x 38 mm

Weight

0.6 KG
