RQ-50B MEANWELL SMPS Power Supply

RQ-50B MEANWELL SMPS Power Supply

Product Details:

  • Output Current 5 / 1 / 0.5 / 0.5 Ampere (amp)
  • Output Type Triple
  • Phase Single Phase
  • Output Power 50 Watt (w)
  • Input Voltage 88 - 264VAC / 125 - 373VDC Volt (V)
  • Efficiency 74%
  • Weight 0.41 Kilograms (kg)
  • Click to View more
X

RQ-50B MEANWELL SMPS Power Supply Product Specifications

  • Single Phase
  • 74%
  • 0.41 Kilograms (kg)
  • 5 / 1 / 0.5 / 0.5 Ampere (amp)
  • 50 Watt (w)
  • 88 - 264VAC / 125 - 373VDC Volt (V)
  • Triple

Product Description

Brand Name

MEANWELL

Part No

RQ-50B

Input Voltage Range

88 - 264VAC / 125 - 373VDC

Output Voltage

5VDC /  12VDC / -5VDC / -12VDC

Output Current

5Amp / 1Amp / 0.5Amp / 0.5Amp

Output Power

50Watt

Mounting Type

Enclosed / Panel Mount

Protections

Output Short Circuit / Over-Current / Over-Voltage

Efficiency

74%

Certifications

UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved

Dimension

99 x 97 x 36 mm

Weight

0.41 KG
