RQ-125B MEANWELL SMPS Power Supply

RQ-125B MEANWELL SMPS Power Supply

Product Details:

  • Output Current 11 / 4.5 / 1 / 0.5 Ampere (amp)
  • Output Type Quad
  • Phase Single Phase
  • Output Power 125 Watt (w)
  • Input Voltage 88 - 132VAC / 176 - 264VDC Volt (V)
  • Efficiency 77%
  • Weight 0.7 Kilograms (kg)
  • Click to view more
X

Product Specifications

  • 0.7 Kilograms (kg)
  • 11 / 4.5 / 1 / 0.5 Ampere (amp)
  • 125 Watt (w)
  • 77%
  • Single Phase
  • 88 - 132VAC / 176 - 264VDC Volt (V)
  • Quad

Product Description

Brand Name

MEANWELL

Part No

RQ-125B

Input Voltage Range

88 - 132VAC / 176 - 264VDC

Output Voltage

5VDC /  12VDC / -5VDC / -12VDC

Output Current

11Amp / 4.5Amp / 1Amp / 0.5Amp

Output Power

125Watt

Mounting Type

Enclosed / Panel Mount

Protections

Output Short Circuit / Over-Current / Over-Voltage

Efficiency

77%

Certifications

UL62368-1, TUV BS EN/EN62368-1, EAC TP TC 004 approved

Dimension

199 x 8 x 38 mm

Weight

0.7 KG
