NDR-75-24 MEANWELL SMPS Power Supply

NDR-75-24 MEANWELL SMPS Power Supply

Product Details:

  • Output Current 3.2 Ampere (amp)
  • Output Type Single
  • Phase Single Phase
  • Output Power 75 Watt (w)
  • Input Voltage 90 - 264VAC / 127 - 370VDC Volt (V)
  • Efficiency 88%
  • Weight 0.51 Kilograms (kg)
  • Click to view more
X

Product Specifications

  • 3.2 Ampere (amp)
  • Single Phase
  • 75 Watt (w)
  • Single
  • 88%
  • 0.51 Kilograms (kg)
  • 90 - 264VAC / 127 - 370VDC Volt (V)

Product Description

Brand Name

Meanwell

Part No

NDR-75-24

Input Voltage Range

90 - 264VAC / 127 - 370VDC

Output Voltage

24VDC

Output Adjustable Voltage Range

24VDC -28VDC

Output Current

3.2Amp

Output Power

75 Watt

Mounting Type

Din Rail / Channel Mount

Protections

Short Circuit / Overload / Over Voltage / Over Temperature

Efficiency

88%

Certifications

UL508,TUV BS EN/EN62368-1,EAC TP TC 004,BSMI CNS14336-1,IS13252(Part1)/IEC60950-1 approved;(meet BS EN/EN60204-1

Dimension

32 x 125.2 x 102 mm

Weight

0.51 KG
