NDR-480-24 Meanwell SMPS Power Supply

NDR-480-24 Meanwell SMPS Power Supply

5850 INR/Unit

Product Details:

  • Application Industrial Automation / Controll Panel / LED Light
  • Output Type Single
  • Output Current 20 Ampere (amp)
  • Output Power 480 Watt (w)
  • Input Voltage 90 - 264 Volt (V)
  • Weight 1.5 Kilograms (kg)
  • Click to view more
X

Price And Quantity

  • 5850 INR/Unit
  • 1 Unit

Product Specifications

  • 20 Ampere (amp)
  • Single
  • Industrial Automation / Controll Panel / LED Light
  • 90 - 264 Volt (V)
  • 480 Watt (w)
  • 1.5 Kilograms (kg)

Trade Information

  • Cash Advance (CA)
  • 7 Days
  • All India

Product Description

We are a noteworthy manufacturer of NDR-480-24 Meanwell SMPS Power Supply in the market. This is made using best in grade raw material and machinery at our unit in adherence with the industrial prevailing standards and norms. NDR-480-24 Meanwell SMPS Power Supply can be availed from us at highly feasible rates.

Product Details:

Output Current20 Amp
Input Voltage Range
90 - 264VAC & 127 - 370VDC
Usage/ApplicationIndustrial Automation / Controll Panel / LED Light
Part NumberNDR-480-24
Warranty3 Years
Mounting TypeDin Rail Mount / Channel Mount
Output Power480 Watt
Input Current4.8A/115VAC & 2.4A/230VAC
Output TypeSingle
Mtbf146.8K hrs min. MIL-HDBK-217F (25 Deg C)
Dimensions85.5 x 125.2 x 128.5mm (W x H x D)
SeriesNDR-480
Efficiency92.5%
Working Humidity20 - 95% RH Non-Condensing
DesignSmps
ProtectionShort Circuit / Overload / Over Voltage / Over Temperature
BrandMeanwell
Input Frequency47 - 63Hz
Storage Temperature-40 to +85 Deg C & 10 - 95% RH
Working Temp.-20 to +70 Deg C
Adjustable Voltage24 - 28VDC
PhaseSingle Phase
Output Voltage24VDC
Weight1.5 Kg
CertificationsCE / CB / UL / EAC
Ripple And Noise150mVp-p
