Meanwell Dealer SMPS Power Supply

Price 680 INR/ Piece

Get a Price/Quote

Meanwell Dealer SMPS Power Supply Specification

Connector Type
Screw Terminal

Output Current
12.5A

Working Temperature
-20C to +60C

Features
Compact Size, High Reliability, Low Ripple

Power Factor
>0.95

Application
Industrial Automation, LED Lighting, CNC Machinery

Cooling Method
Natural Air Cooling

Noise Level
<60dB

Current Range
0~12.5A

Operating Temperature
-20C to +60C

Rated Current
12.5A

Power Supply
AC-DC

Output Type
Single Output

Rated Power
150W

Phase
Single Phase

Product Type
SMPS Power Supply

Output Power
150W

Output Frequency
47~63Hz

Input Voltage
85~264V AC

Voltage Protection
Over Voltage, Over Load, Short Circuit

Efficiency
88% (typical)

Material
Metal Enclosure

Line Regulation
0.5%

Storage Temperature
-40C to +85C

Weight
0.65 kg

Humidity
20%~90% RH non-condensing

MTBF
>300,000 hours

Model Number
LRS-150-12

Adjustable Output Voltage
10.2V to 13.5V

Protection Class
Class I

Dimension
159 × 97 × 30 mm

Remote ON/OFF Control
Supported

Isolation Voltage
3kV AC

Output Voltage
12V DC

Startup Time
<1s at full load

Leakage Current
<2mA / 240VAC

Vibration Resistance
10~500Hz, 2G 10min/1cycle, period for 60min

Hold Up Time
>20ms at full load

About Meanwell Dealer SMPS Power Supply

We have been serving our clients with a quality tested range of Meanwell Dealer SMPS Power Supply in the market. This is used at several places to cater to the demands of our customers. Supreme grade material is sourced from our reputed vendors and processed using hi tech machinery at our unit for making Meanwell Dealer SMPS Power Supply.

Technical Specification

Output Current	17A / 18A / 20A / 23A / 25A / 30A / 35A / 40A / 50A / 60A / 70A / 100A / 125A / 150A / 300A
Certifications	CE / CB / CQC / UL / EMC
Output Voltage	3.3VDC / 4.2VDC / 5VDC / 9VDC / 12VDC / 15VDC / 24VDC / 27VDC / 36VDC / 48VDC
Phase	Single Phase
Working Temp.	-25 to +70 Deg C
Storage Temperature	-40 to +85 Deg C & 10 - 95% RH Non-Condensing
Input Frequency	47 - 63Hz
Brand	Meanwell
Protection	Short Circuit / Overload / Over Voltage / Over Temperature
Design	Smps
Working Humidity	20 - 90% RH Non-Condensing
Efficiency	78% to 91%
Series	RS / LRS / SE
Output Type	Single
Output Power	15W / 25W / 35W / 50W / 75W / 100W / 150W / 200W / 350W / 450W / 600W / 1000W / 1500W
Mounting Type	Panel Mount / Enclosed
Warranty	3 Years
Usage/Application	Industrial Automation / Controll Panel / LED Light
Input Voltage Range	85 - 264VAC / 180 -264VAC / 240 - 370VDC

Versatile Industrial Performance

Designed to accommodate demanding environments, the LRS-150-12 operates reliably in a wide temperature range (-20C to +60C) and tough humidity conditions (20%-90% RH non-condensing). With outstanding vibration resistance (10~500Hz, 2G), this power supply is suitable for industrial automation, LED lighting, and CNC machinery, ensuring uninterrupted, stable power for critical operations.

High Reliability and Safety

Safety and durability are integral, offering a high MTBF (>300,000 hours) and essential protection features. Isolation voltage up to 3kV AC and low leakage current (<2mA / 240VAC) provide peace of mind, while rapid startup (<1s at full load) and long hold-up time (>20ms) maintain system integrity during power fluctuations.

Efficient and User-Friendly Design

With an 88% typical efficiency and a power factor above 0.95, the LRS-150-12 maximizes energy savings while minimizing heat generation. Remote ON/OFF control, adjustable output voltage, and screw terminal connectors enable flexible integration and simplified installation. The compact 159 97 30 mm housing makes it ideal for installations where space is at a premium.

FAQ's of Meanwell Dealer SMPS Power Supply:

Q: How can I adjust the output voltage of the LRS-150-12 power supply?

A: The LRS-150-12 features an adjustable output voltage range from 10.2V to 13.5V. You can fine-tune the output using the built-in adjustment potentiometer provided on the unit, allowing for optimal compatibility with your application requirements.

Q: What protection features are included with this SMPS power supply?

A: This model is equipped with over voltage, over load, and short circuit protection to safeguard both your connected devices and the power supply itself, ensuring reliable and safe operation in industrial settings.

Q: Where is the LRS-150-12 commonly used, and who typically supplies it in India?

A: The LRS-150-12 is popularly used in industrial automation systems, LED lighting setups, and CNC machinery. It is available through authorized manufacturers, suppliers, traders, and wholesalers across India.

Q: What is the process for remotely controlling the ON/OFF function of this device?

A: Remote ON/OFF control is supported by connecting compatible external switches to the designated screw terminals. This function enables you to manage power supply operation without physically accessing the unit, adding convenience for automated setups.

Q: When is it beneficial to choose the LRS-150-12 for industrial applications?

A: This power supply is ideal when your project demands high reliability, a compact footprint, and stable output under challenging operating conditions, such as varying temperatures or vibration-prone environments.

Q: What are the key usage guidelines for the LRS-150-12 to ensure optimal performance?

A: Ensure the unit is installed within its rated working temperature (-20C to +60C) and humidity range (20%~90% RH non-condensing). Connect input and output lines to screw terminals securely, and maintain proper airflow for natural air cooling. Regular inspection helps maintain longevity.

Q: How does the high MTBF benefit users of the LRS-150-12?

A: With an MTBF of over 300,000 hours, the LRS-150-12 minimizes the risk of unexpected failures and reduces maintenance costs, offering consistent operation ideal for mission-critical industrial environments.
