MDR-40-48 MEANWELL SMPS Power Supply

MDR-40-48 MEANWELL SMPS Power Supply

Product Details:

  • Output Type Single
  • Phase Single Phase
  • Output Current 0.83 Ampere (amp)
  • Output Power 40 Watt (w)
  • Input Voltage 85 - 264VAC / 120 - 370VDC Volt (V)
  • Efficiency 88%
  • Weight 0.3 Kilograms (kg)
  • Click to view more
X

Product Specifications

  • Single
  • Single Phase
  • 0.83 Ampere (amp)
  • 88%
  • 40 Watt (w)
  • 85 - 264VAC / 120 - 370VDC Volt (V)
  • 0.3 Kilograms (kg)

Product Description

Brand Name

Meanwell

Part No

MDR-40-48

Input Voltage Range

85 - 264VAC / 120 - 370VDC

Output Voltage

48VDC

Output Adjustable Voltage Range

48VDC - 56VDC

Output Current

0.83Amp

Output Power

40 Watt

Mounting Type

Din Rail / Channel Mount

Protections

Short Circuit / Overload / Over Voltage / Over Temperature

Efficiency

88%

Certifications

UL508,TUV BS EN/EN62368-1,EAC TP TC 004,BSMI CNS14336-1,IS13252(Part1)/IEC60950-1 approved;(meet BS EN/EN60204-1

Dimension

40 x 90 x 100 mm

Weight

0.3 KG
