LM75-10C051212-28 MORNSUN SMPS Power Supply

LM75-10C051212-28 MORNSUN SMPS Power Supply

Product Details:

  • Phase Single Phase
  • Output Current 6 / 2.8 / 0.5 Ampere (amp)
  • Output Type Triple
  • Output Power 75 Watt (w)
  • Input Voltage 90 - 264VAC / 120 - 370VDC Volt (V)
  • Efficiency 82%
  • Weight 0.32 Kilograms (kg)
  • Click to view more
X

Product Specifications

  • 6 / 2.8 / 0.5 Ampere (amp)
  • 90 - 264VAC / 120 - 370VDC Volt (V)
  • Single Phase
  • 82%
  • Triple
  • 75 Watt (w)
  • 0.32 Kilograms (kg)

Product Description

 Brand Name  Mornsun
 Part No  LM75-10C051212-28
 I]nput Voltage Range  90 - 264VAC / 120 - 370VDC
 Output Voltage  +5VDC / +12VDC / -12VDC
 Output Adjustable Voltage Range
 Output Current  6Amp / 2.8Amp / 0.5Amp
 Output Power  75 Watt
 Mounting Type  Enclosed / Panel Mount
 Protections  Output Short Circuit / Over-Current / Over-Voltage
 Efficiency  82% At 230VAC
 Certifications  EN / UKCA / BIS
 Dimension  129 x 97 x 30 mm
 Weight  0.32 KG
