LM200-10B05 MORNSUN SMPS Power Supply

LM200-10B05 MORNSUN SMPS Power Supply

Product Details:

  • Output Type Single
  • Output Current 30 Ampere (amp)
  • Phase Single Phase
  • Output Power 200 Watt (w)
  • Input Voltage 90 - 132VAC / 180 - 264VDC Volt (V)
  • Efficiency 87%
  • Weight 0.52 Kilograms (kg)
  • Click to view more
X

Product Specifications

  • 200 Watt (w)
  • Single Phase
  • Single
  • 87%
  • 90 - 132VAC / 180 - 264VDC Volt (V)
  • 0.52 Kilograms (kg)
  • 30 Ampere (amp)

Product Description

 Brand Name  Mornsun
 Part No  LM200-10B05
 Input Voltage Range  90 - 132VAC / 180 - 264VDC
 Output Voltage  5VDC
 Output Adjustable Voltage Range  4.5VDC - 5.5VDC
 Output Current  30Amp
 Output Power  200 Watt
 Mounting Type  Enclosed / Panel Mount
 Protections  Output Short Circuit /  Over-Current / Over-Voltage
 Efficiency  87% At 230VAC
 Certifications  UL / EN / IEC / CQC / BIS / UKCA
 Dimension  179 x 99 x 30 mm
 Weight  0.52 KG
