HDR-30-48 MEANWELL SMPS Power Supply

HDR-30-48 MEANWELL SMPS Power Supply

Product Details:

  • Phase Single Phase
  • Output Type Single
  • Output Current 0.75 Ampere (amp)
  • Output Power 30 Watt (w)
  • Input Voltage 85 -264VAC (277VAC OPERATIONAL) 120 -370VDC (390VDC OPERATIONAL ) Volt (V)
  • Efficiency 90%
  • Weight 0.12 Kilograms (kg)
  • Click to View more
X

HDR-30-48 MEANWELL SMPS Power Supply Product Specifications

  • 0.12 Kilograms (kg)
  • Single
  • 0.75 Ampere (amp)
  • 90%
  • 30 Watt (w)
  • 85 -264VAC (277VAC OPERATIONAL) 120 -370VDC (390VDC OPERATIONAL ) Volt (V)
  • Single Phase

Product Description

Brand Name  Meanwell
 Part No  HDR-30-48
 Input Voltage Range  85 -264VAC (277VAC OPERATIONAL)   120 -370VDC    (390VDC OPERATIONAL )
 Output Voltage  48VDC
 Output Adjustable Voltage Range  43.2VDC - 55.2VDC
 Output Current  0.75Amp
 Output Power  30 Watt
 Mounting Type  Din Rail / Channel Mount
 Protections  Short Circuit / Overload / Over Voltage / Over Temperature
 Efficiency  90%
 Certifications  UL62368-1, UL508, TUV BS EN/EN61558-2-16, BS    EN/EN61558-1, IEC62368-1, EAC TP TC 004, BSMI   CNS14336-1 approved;
 Design refer to TUV BS EN/EN62368-1
 Dimension  35 x 90 x 54.5 mm
 Weight  0.12 KG
