HDR-100-48 MEANWELL SMPS Power Supply

HDR-100-48 MEANWELL SMPS Power Supply

Product Details:

  • Phase Single Phase
  • Output Type Single
  • Output Current 1.92 Ampere (amp)
  • Output Power 100 Watt (w)
  • Input Voltage 85 -264VAC (277VAC OPERATIONAL) 120 -370VDC ( 390VDC OPERATIONAL ) Volt (V)
  • Efficiency 90%
  • Weight 0.27 Kilograms (kg)
  • Click to view more
X

Product Specifications

  • Single
  • Single Phase
  • 85 -264VAC (277VAC OPERATIONAL) 120 -370VDC ( 390VDC OPERATIONAL ) Volt (V)
  • 1.92 Ampere (amp)
  • 100 Watt (w)
  • 90%
  • 0.27 Kilograms (kg)

Product Description

 Brand Name  Meanwell
 Part No  HDR-100-48
 Input Voltage Range  85 -264VAC (277VAC OPERATIONAL)   120 -370VDC    (390VDC OPERATIONAL )
 Output Voltage  48VDC
 Output Adjustable Voltage Range  48VDC - 48.7VDC
 Output Current  1.92Amp
 Output Power  100 Watt
 Mounting Type  Din Rail / Channel Mount
 Protections  Short Circuit / Overload / Over Voltage / Over Temperature
 Efficiency  90%
 Certifications  UL508,TUV BS EN/EN62368-1,EAC TP TC 004,BSMI   CNS14336-1,IS13252(Part1)/IEC60950-1 approved;(meet   BS EN/EN60204-1
 Dimension  70 x 90 x 54.5 mm
 Weight  0.27 KG
