24VDC 62.5A MEANWELL SMPS Power Supply

Product Details:

Working Temperature -20C to +60C
Features Short Circuit Protection Overload Protection Over Voltage Protection Over Temperature Protection
Connector Type Screw Terminal
Rated Current 62.5A
Noise Level Low noise operation
Operating Temperature -20C to +60C
Power Factor PF>0.95 at full load
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

24VDC 62.5A MEANWELL SMPS Power Supply Product Specifications

Output Frequency 50/60Hz
Efficiency Up to 93%
Current Range 0-62.5A
Product Type 24VDC 62.5A Power Supply
Noise Level Low noise operation
Operating Temperature -20C to +60C
Line Regulation 0.5%
Power Factor PF>0.95 at full load
Rated Current 62.5A
Connector Type Screw Terminal
Working Temperature -20C to +60C
Features Short Circuit Protection Overload Protection Over Voltage Protection Over Temperature Protection
Material Metal
Output Power 1500W
Application Industrial Automation
Weight 2.5 Kg
Storage Temperature -40C to +85C
Phase Single Phase
Cooling Method Built-in Fan
Output Type DC
Power Supply Switch Mode Power Supply (SMPS)
Rated Power 1500W
Output Current 62.5A
Voltage Protection Over Voltage Protection
Input Voltage 90-264VAC 127-370VDC

Product Description

Brand Name	Meanwell
Part No	SE-1500-24
Input Voltage Range	180 - 264VAC / 254 - 370VDC
Output Voltage	24 VDC
Output Adjustable Voltage Range	21.6VDC - 26.4VDC
Output Current	62.5Amp
Output Power	1500 Watt
Mounting Type	Enclosed / Panel Mount
Protections	Short Circuit / Overload / Over Voltage / Over Temperature
Efficiency	87%
Certifications	UL62368-1, BSMI CNS14336-1, EAC TP TC 004 approved; Design refer to BS EN/EN62368-1
Dimension	278 x 177.5 x 63.5 mm
Weight	3.3 KG
