15VDC 14A MEANWELL SMPS Power Supply

Product Details:

Rated Power 200W
Connector Type Terminal block
Power Supply Switch Mode Power Supply (SMPS)
Phase Single Phase
Output Current 14A
Output Type DC output
Rated Current 14A
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

15VDC 14A MEANWELL SMPS Power Supply Product Specifications

Working Temperature -30C to +70C
Current Range 14A
Noise Level Low noise operation
Weight 0.54 kg
Storage Temperature Storage range from -40C to +85C
Operating Temperature Operating range from -30C to +70C
Output Frequency 50Hz/60Hz
Material Aluminum housing
Application Industrial applications electronic equipment
Cooling Method Convection cooling
Voltage Protection Over-voltage Over-current Short-circuit protection
Input Voltage Universal AC 85-264V
Efficiency High efficiency
Rated Power 200W
Connector Type Terminal block
Power Supply Switch Mode Power Supply (SMPS)
Phase Single Phase
Output Current 14A
Output Power 200W
Output Type DC output
Product Type Power Supply Unit
Rated Current 14A
Line Regulation Low line regulation
Features Compact design high reliability RoHS compliant BIS certified

Product Description

Brand Name	Meanwell
Part No	LRS-200-15
Input Voltage Range	90 - 132VAC / 180 - 264VDC
Output Voltage	15VDC
Output Adjustable Voltage Range	13.5VDC - 18VDC
Output Current	14Amp
Output Power	200 Watt
Mounting Type	Enclosed / Panel Mount
Protections	Short Circuit / Overload / Over Voltage / Over Temperature
Efficiency	88%
Certifications	IEC/UL 62368-1, BSMI CNS14336-1, BS EN/EN60335-1,EAC TP TC 004, KC K60950-1(for LRS-200-12/24 only), BIS IS13252(Part1): 2010/IEC 60950-1: 2005, AS/NZS62368.1 approved; Design refer to BS EN/EN62368-1
Dimension	215 x 115 x 30 mm
Weight	0.66 KG
