Send Inquiry12VDC 2.1A MEANWELL SMPS Power Supply
12VDC 2.1A MEANWELL SMPS Power Supply Specification
- Rated Current
- 2.1A
- Phase
- Single Phase
- Working Temperature
- -20C to +70C
- Operating Temperature
- -20C to +70C
- Rated Power
- 25W
- Features
- Compact design BIS CE RoHS certified
- Current Range
- 2.1A
- Noise Level
- Low Noise
- Output Type
- DC
- Connector Type
- Terminal Block
- Power Supply
- MEANWELL SMPS Power Supply
- Output Current
- 2.1A
- Cooling Method
- Convection Cooling
- Application
- Industrial Power Supply
- Product Type
- Switch Mode Power Supply
- Output Power
- 25W
- Output Frequency
- 50/60Hz
- Input Voltage
- 100-240VAC
- Voltage Protection
- Overload Over voltage Short circuit
- Efficiency
- High Efficiency
- Material
- Metal Enclosure
- Line Regulation
- 0.5%
- Storage Temperature
- -40C to +85C
- Weight
- 0.3kg
About 12VDC 2.1A MEANWELL SMPS Power Supply
|
Brand Name |
Meanwell |
|
Part No |
RS-25-12 |
|
Input Voltage Range |
88 - 264VAC / 125 - 373VDC |
|
Output Voltage |
12VDC |
|
Output Adjustable Voltage Range |
10.8VDC - 13.2VDC |
|
Output Current |
2.1Amp |
|
Output Power |
25 Watt |
|
Mounting Type |
Enclosed / Panel Mount |
|
Protections |
Short Circuit / Overload / Over Voltage / Over Temperature |
|
Efficiency |
81.5% |
|
Certifications |
UL62368-1, TUV BS EN/EN62368-1 , AS/NZS 62368.1, EAC TP TC 004, CCC GB4943.1, BSMI CNS14336-1,BIS IS13252(Part1):2010/IEC 60950-1: 2005 approved |
|
Dimension |
78 x 51 x 28 mm |
|
Weight |
0.2 KG |
